Journal of Medical Cases

Case Report

Volume 4, Number 7, July 2013, pages 471-473

Confusing Difficulty to Breath

With the high prevalence of community-acquired pneumonia, especially during the winter season, the review of this interesting and unusual case of a young adult woman with infectious pulmonary symptoms, central nervous system involvement and hemolytic anemia is presented.

A 47 year-old female presents herself at the emergency department with fatigue, cough and an involuntary weight loss. She had consulted in another hospital prior to her visit where she was diagnosed with a community-acquired pneumonia and was sent home with amoxicillin / clavulanate for a total of 14 days. However, she still felt ill and she wanted a second opinion.

Ms. X is not known for any significant disease and had only had an acute pyelonephritis and a bronchitis in the past. She is also a smoker with 15 packs-year. She had undergone an ovariectomy. She was born in the Democratic Republic of the Congo and had lived a few years in Belgium before moving to Canada.

Upon her arrival, her vital signs are stable, apart from a tachycardia of 114 beats per minute and a saturation of 95 % with ambient air. She has a non-productive cough and crepitants could be heard at the base of the left lung.

It is noted that she has few signs of CNS involvement: sleepiness, disorganisation and disorientation. She had also visual hallucinations and possibly a paranoid delirium before coming to the emergency according to her son.

She is found to be in an inflammatory state with her sedimentation rate at 137 mm/H (upper limit of normal range 20 mm/H), her C-reactive protein at 21 mg/L (upper limit of normal range 5 mg/L) and her ferritin at 1886 ug/L (upper limit of normal range 90 ug/L for her age and sex). Ms. X’s white blood cells are at 21.2 × 10⁹/L (upper limit of normal range 11 × 10⁹/L) with neutrophils at 14.4 × 10⁹/L (upper limit of normal range 7.7 × 10⁹/L) and her platelets at 656 × 10⁹/L (maximum of 743 - upper limit of normal range 450 × 10⁹/L).

On the pulmonary X-ray, we can see a bilateral pattern of reticulo-nodularity (Fig. 1). Pneumonia is diagnosed and she is switched to daily levofloxacin 500 milligrams.

Click for large image

Figure 1. Ms X’s lung X-ray showing the bilateral pattern of reticulo-nodularity.

A normocytic normochromic anemia is discovered with a hemoglobin level of 78 g/L, rapidly progressing to 61 g/L with a normal iron profile, as her TSH, B12 vitamin and folic acid. A haemolytic anemia is diagnosed with LDH at 720 U/L (upper limit of normal range 205 U/L) and haptoglobin less than 0.07 g/L (lower limit of normal range 0.35 g/L). This anemia is found to be reactive with cold agglutinins anti-I IgM.

Two blood transfusions and a heated room were needed to stabilise the patient.

We can see cold agglutinins hemolytic anemia in Figure 2.

Click for large image

Figure 2. Cold agglutinins hemolytic anemia. Courtesy of Professor Kristine Krafts, md, University of Minnesota School of Medicine.

Within the differential diagnosis of the clinical picture we eliminated HIV (negative antibody and antigen), syphilis (negative EIA), systemic erythematous lupus (negative anti-nuclear antibody, normal complement 3 and 4), tuberculosis (negative serology and 4 negative Zielh) and mononucleosis (negative monotest). She underwent a full work-up for neoplastic or autoimmune disease (cerebral, thoracic and abdominal scans and a mammography) which came back negative. Finally, the M. pneumonia serology came back positive with both IgG at 8.91 (upper limit of normal range 1.10) and IgM at 8.57 (same upper limit as IgG) in this clinical setting of pneumonia with a cold agglutinin haemolytic anemia and CNS involvement. The pulmonary X-ray 8 days post-admission showed an almost resolution of the reticulo-nodular pattern.

M. pneumonia, hominis and genitalium are the three species of Mycoplasma mostly involved in human infections. They are short rods that cannot be Gram stained (they do not have a cell wall) [1]. They can grow both in aerobic and anaerobic media. Mycoplasma belongs to the class of Mollicutes, along with Ureaplasma.

M. pneumonia is one of the common atypical germs involved in community-acquired pneumonia. It usually affects children or military recruits, but can also be found in adults [2]. Clinically, it can vary from almost no symptoms, upper respiratory tract symptoms only, to pneumonia with or without extrapulmonary symptoms, and even empyema.

The involvement of extrapulmonary organs can occur not only by autoimmunity, but also by direct invasion [1]. Of the extrapulmonary symptoms, the neurological ones are the most frequent with encephalitis [3]. Other organ implications can be hematologic (IgM cold agglutinins) through autoantibodies against M. pneumonia’s glycolipid antigens [4]. This cold agglutinin hemolytic anemia is also rarely clinically significant, which makes our patient’s case even more unusual as she had her hemoglobin level dropped down to 61 g/L and necessitated blood transfusions.

Otherwise, the cardio-vascular system can be affected with symptoms of pericarditis and arrhythmia. The renal (glomerulonephritis) and gastrointestinal (hepatitis, pancreatitis) systems may also be affected. Rheumatologic (arthritis, Raynaud) and skin (rash) involvement are possible as well [2]. Hence, other clinical and para-clinical investigations would implicate an electrocardiogram, a urine analysis, liver and pancreatic enzymes and a careful exam of skin and joints, so as to eliminate synovitis or an associated rash.

Because transmission of M. pneumonia is by airborne droplets and as of the potential hematologic complication, patients infected with M. pneumonia need to be isolated in a warm room. Treatment is often empirically started with a macrolide (azithromycin, clarithromycin or erythromycin) or a fluoroquinolone (levofloxacin or moxifloxacin) or a tetracycline derivative (doxycycline) for a total of 7 to 14 days [1, 5]. Resistance in North America to these antibiotics is low.

When a patient presents infectious pulmonary symptoms and central nervous system involvement, it is important to look for Mycoplasma pneumonia with a serologic test. If suspected, treatment involves macrolides, fluoroquinolones or doxycycline. A respiratory isolation in a warm room is necessary in order to prevent the spread of the disease and the apparition or complications of cold-agglutinins hemolytic anemia.

1. Atkinson TP, Balish MF, Waites KB. Epidemiology, clinical manifestations, pathogenesis and laboratory detection of Mycoplasma pneumoniae infections. FEMS Microbiol Rev. 2008;32(6):956-973.
   doi pubmed
2. Kashyap S, Sarkar M. Mycoplasma pneumonia: Clinical features and management. Lung India. 2010;27(2):75-85.
   doi pubmed
3. Waites KB, Balish MF, Atkinson TP. New insights into the pathogenesis and detection of Mycoplasma pneumoniae infections. Future Microbiol. 2008;3(6):635-648.
   doi pubmed
4. Khan FY, M Ay. Mycoplasma pneumoniae associated with severe autoimmune hemolytic anemia: case report and literature review. Braz J Infect Dis. 2009;13(1):77-79.
   doi
5. Goto H. Multicenter surveillance of adult atypical pneumonia in Japan: its clinical features, and efficacy and safety of clarithromycin. J Infect Chemother. 2011;17(1):97-104.
   doi pubmed
