Journal of Medical Cases

Case Report

Volume 9, Number 1, January 2018, pages 8-10

On-Pump Coronary Artery Bypass Grafting in a Patient With Renal Transplant and Familial Hypercholesterolemia

Coronary artery bypass grafting (CABG) is frequently used worldwide. Coronary artery bypass operation is performed while the heart is stopped and using cardiopulmonary bypass machine is called on-pump CABG [1]. The surgical procedure involves renal, cardiac, cerebral, and respiratory risks [2].

Familial hypercholesterolemia (FH) is an autosomal dominant disease, which is characterized by high total cholesterol (TC) and low-density lipoprotein (LDL) cholesterol levels from birth. It is a major cause of premature coronary heart disease, and needs to be treated with CABG surgery at an early age [3].

Renal transplantation is a form of treatment in patients with end-stage renal disease [4]. The immunosuppressive drugs used after kidney transplantation increase the risk of CABG surgery.

We present a different case in our clinic, in which on-pump CABG was performed in a young patient with renal transplant and had diagnosed hypercholesterolemia.

A 19-year-old male patient presented to the cardiology clinic with complaints of chest pain during efforts for a month. He had a history of renal transplantation when he was 12 years old. He had no history of diabetes mellitus, hypertension, smoking and family history of coronary artery disease. He had been diagnosed with FH. He has taken the immunosuppressive drug cyclosporin (SANDIMMUN^® Neoral 25 mg) and mycophenolatmofetil (Cellcept^® 500 mg) due to renal transplantation and statin (Alvastin^® 80 mg) due to hyperlipidemia.

His physical examination results showed no abnormalities. Vital findings were within normal range: fever 36.7 °C, blood pressure arterial 110/60 mm Hg with a regular pulse of 74 beats/min, respiration rate 14/min, and saturation with 94%/96% with pulse oximeter. In his physical examination, heart sounds were rhythmic and no additional sound murmur was detected. All peripheral pulses were palpable. Both hemithoraxes participated in respiration equally, and there was no ral-rhonchus. There was no distension, rebound or tenderness in abdomen. In local examination, there was the renal transplantation scar.

On laboratory investigation, cardiac markers were normal; GFR 79 mL/min/1.73 m² (normal range > 60), blood urine nitrogen 20 mg/dL, creatinine 1.3 mg/dL, serum cyclosporin level 77 ng/mL, serum total cholesterol 596 mg/dL (normal range 130 - 200 mg/dL), HDL cholesterol 42 mg/dL (normal range 130 - 200 mg/dL), LDL cholesterol 533 mg/dL (normal range 60 - 130 mg/dL), and triglyceride 106 (normal range 50 - 160 mg/dL) were determined.

An electrocardiogram showed ST-T changes (common ST depression). Echocardiography showed normal ventricular function with no cardiac valve pathology. Coronary angiogram revealed over 75% stenosis at the proximal left anterior descending artery (LAD) (Fig. 1), Cx coronary artery (Fig. 2) and right coronary artery (Fig. 3).

Click for large image

Figure 1. LAD lesion.

Click for large image

Figure 2. Cx lesion.

Click for large image

Figure 3. RCA lesion.

The patient was referred to cardiovascular surgery clinic for CABG surgery. The immunosuppressive and statin drugs were used until operation day. On-pump CABG surgery (LIMA-LAD, DI, Cx (OMI), and RCA (PD)) was performed. Because of the posssibility of renal failure that led to requirement of hemodialysis and AV fistula, safen vein conduit was preferred instead of radial vein. At the end of the operation, low-dose dopamine (3 µg/kg/dk) and nitroglycerin infusion were given and patient was taken to ICU. Because of the fast-track anesthesia, patient was early extubated. Mobilization on the first postoperative day was achieved. Drains were removed on second postoperative day. After routine CABG follow-up, he was discharged on eighth day postoperatively. The last follow-up was 5 months after the surgery and he was remarkably well.

CABG is a cardiac surgery procedure which is usually applied over 50 years of age. Although risks and benefits are individualized and depend on surgical technique, cerebrovascular events and renal insufficiency are main complications [5].

FH is a genetic disorder that clinically leads to an increase in plasma cholesterol levels. It increases three- to six-fold in homozygous carriers of FH mutations and two- to three-fold in heterozygous. FH patients often have coronary artery disease at second and third decades of their life; however, a 7-year-old FH patient had CABG as reported in the literature [6].

Development of atherosclerotic plaque deposition may also occur in the aorta at an early age in patients with FH, as in our case. Therefore, we think that importance of the good examination of the aorta during aortic cannulation in CABG operations should be emphasized in patient with FH. My opinion is that it is getting more value of cannulation in the appropriate area and the side clamping in once at the clean area in the patients that aortic plaque placement is probable just like our case who has aortic soft plaque.

We also thought that in our case, 19-year-old male undergoing renal transplantation, the CABG operation has a higher risk of renal damage compared to the normal individual. In literature, data on the long-term outcomes and risk factors in this population are scarce; however, transient deterioration of graft function has been reported. In our case, as the patient had a history of renal transplantation, and is administered immunosuppressants, he is susceptible to infection or rejection.

In our case, as the patient was in the acute phase after renal transplantation, prevention of rejection was thought to be of the utmost importance. Moreover, the use of cardiopulmonary bypass (CPB) in open heart surgery causes renal function and levels of immunosuppressants to become unstable. In our case, the particular attention is focused on the method used for administering immunosuppressants to this patient perioperatively. Preoperative immunosuppression which continued until the morning of the surgery was restarted as soon as possible postoperatively. Drugs was administered orally the night after surgery.

Immunosuppressive agents taken until operation day and its starting to take medicine as soon as possible after extubation are good managements for prevention from rejection. Their negative effect on renal function cannot be denied. Attention is paid to hypervolemia and hyperpotassemia in patients undergoing standard on-pump CABG. However, in such patients with kidney transplant and FH, more care should be taken. I think that do not hesitate performing intraoperative ultrafiltration just as we did.

On-pump CABG can be performed succesfully in patient with renal transplant. However, renal recipients have higher risk of infection and renal damage compared with patients without transplants. In addition, as in our case, FH would affect the clinical outcome negatively.

Our precautions to be taken into consideration to prevent renal damage and infection for the patient with a history of renal transplantation include mediastinal washing, achieving adequate hemostasis, intraoperative ultrafitration, using blood product as little as possible, for protection of infection avoiding unnecessary cautery, and multidisciplinary approach with nephrology department is also important to manage the treatment especially in perioperative period.

I would like to think the sensitivity and close follow-up in standard CABG cases, and it should be applied to the highest level in such patients.

Conflict of Interest

None.

1. Lassnigg A, Hiesmayr MJ, Bauer P, Haisjackl M. Workgroup on Postoperative Intensive Care of the European Society of Intensive Care M, European Workgroup of Cardiothoracic I. Effect of centre-, patient- and procedure-related factors on intensive care resource utilisation after cardiac surgery. Intensive Care Med. 2002;28(10):1453-1461.
   doi pubmed
2. Levy JH, Tanaka KA. Inflammatory response to cardiopulmonary bypass. Ann Thorac Surg. 2003;75(2):S715-720.
   doi
3. Kawasuji M, Sakakibara N, Takemura H, Matsumoto Y, Mabuchi H, Watanabe Y. Coronary artery bypass grafting in familial hypercholesterolemia. J Thorac Cardiovasc Surg. 1995;109(2):364-369.
   doi
4. Magee CC, Pascual M. Update in renal transplantation. Arch Intern Med. 2004;164(13):1373-1388.
   doi pubmed
5. Hillis LD, Smith PK, Anderson JL, Bittl JA, Bridges CR, Byrne JG, Cigarroa JE, et al. 2011 ACCF/AHA Guideline for Coronary Artery Bypass Graft Surgery. A report of the American College of Cardiology Foundation/American Heart Association Task Force on Practice Guidelines. Developed in collaboration with the American Association for Thoracic Surgery, Society of Cardiovascular Anesthesiologists, and Society of Thoracic Surgeons. J Am Coll Cardiol. 2011;58(24):e123-210.
   doi pubmed
6. Ersoy U, Guvener M. Coronary revascularization in seven-year-old boy with homozygous familial hypercholesterolaemia. Acta Paediatr. 2000;89(12):1501-1502.
   doi pubmed
